TM 9-2330-371-14&P
SPARE TIRE AND WHEEL ASSEMBLY
This task covers:
a. Removal (page 3-15)
b. Installation (page 3-15)
INITIAL SETUP
Tools
Personnel Required
Wrench, lug
Two
ACTION
ITEM
LOCATION
REMARKS
REMOVAL
Two lug nuts (2)
1.
Gooseneck (1)
Using lug wrench, unscrew and take off.
Spare tire and wheel
2.
With assistant, lift to clear lugs (4).
assembly (3)
INSTALLATION
Spare tire and wheel
Gooseneck (1)
3.
With assistant, put tire and wheel
assembly (3)
assembly (3) on lugs (4).
Two lug nuts (2)
Two lugs (4)
4.
Put on and tighten using lug wrench.
NOTE
As soon as possible, notify organizational
maintenance of tire change. Have organizational
maintenance repair bad tire.
TASK ENDS HERE
