TM 9-2330-381-14
4-107. MECHANICAL THROTTLE CONTROL (CONT)
REMOVAL
1.
Remove spring (1).
2.
Loosen bolt (2) and disconnect throttle cable (3) from control lever (4).
3.
Remove nut (5) and washer (6) from throttle cable (3).
4.
Pull throttle cable (3) from bracket (7). Remove washer (8) and nut (9) from throttle cable (3).
INSTALLATION
1.
Install nut (9) and washer (8) on throttle cable (3).
2.
Push throttle cable (3) through bracket (7) and install washer (6) and nut (5). Insert throttle cable (3) into control
lever (4) and tighten bolt (2).
3.
Install spring (1).
FOLLOW-ON MAINTENANCE
Lower step assembly (para. 2-16).
4-504
