TM 9-2590-209-14&P
Be sure that all the old lubricants and foreign materials
NOTE
are removed from the lubrication ptss, ges.
Procedures for both left and right sides are the same.
d. Inspection. Inspect surfaces for cracks, breaks,
nicks or burrs, and replace if necessary.
Polish
(1) Disconnect lines carefully to
relieve
accessible machined surfaces with crocus cloth and then
wash with drycleaning solvent.
(2) Remove four screws securing top guard
(3) Remove four screws, lockwashers, and
NOTE
washers securing top guard to front guard, and remove
top guard (view B).
Procedures for both left and right sides are the same.
(4) Remove two screws, lockwashers, and
(1) Position cylinder assembly on mounting
washers securing front guard, and remove front guard
bracket (view F).
(view B).
(2) Install pin securing pushbeam to ram
(5) Remove four screws, lockwashers, and
assembly; secure with screw, lockwasher, and lock
washers securing rear guard, and remove rear guard
(view F).
(view C).
(3) Connect reducer, elbow, two nipples,
(6) Remove four screws and lockwashers
elbow, seal assembly, and elbow to bottom of cylinder
securing two caps to mounting bracket, and remove
assembly (view E).
caps (view D).
(4) Connect reducer and elbow to top of
cylinder assembly (view E).
NOTE
(5) Connect two hose assemblies to cylinder
Take care when loosening or tightening hose to avoid
assembly (view E).
damage by twisting and turning.
(6) Install two caps to mounting bracket, and
(7) Disconnect two hose assemblies from
cylinder assembly (view E).
(7) Install rear guard, and secure with four
(8) Disconnect elbow and reducer from top of
cylinder assembly (view E).
(8) Install front guard, and secure with two
(9) Disconnect elbow, seal assembly, elbow,
two nipples, elbow, and reducer from bottom of cylinder
assembly(view E).
(9) Install top guard, and secure with four
(10) Remove screw, lockwasher, and lock
securing pin to pushbeam and ram assembly; remove
(10) Install four screws securing top guard
pin (view F).
(view A).
(11) Remove cylinder assembly from mounting
bracket (view F).
c. Cleaning. Clean all parts with drycleaning solvent.
10-39
