TM 9-4120-407-14
(3) Service Valve Cover
(a) Install cover (6) Figure 3-12, six screws (3), new lock washers (4), and flat washers (5).
(b) Close condenser discharge air deflector door (2) and tighten two turnlock fasteners (1).
(c) Roll down and secure fabric cover. See paragraph 2-7.
(4) Connector Cover Plates.
NOTE
The unit can have as many as three connector cover plates, the
following procedure applies to each one individually.
(a) Install cover (3) Figure 3-13, four screws (2), and new self locking nuts (1).
(b) Install lower front panel per step b., (7).
(5) Condenser Fan Covers. Install cover (3) Figure 3-14, four screws (1), and flat washers (2). Repeat
for second cover.
( 6 ) Top Panel.
(a) Be sure mist eliminator bracket (6) Figure 3-15 end notches are aligned over mounting holes and
carefully install cover (5).
(b) Install seven screws (3) and flat washers (4).
(c) Install 11 screws (1) and flat washers (2).
(d) Install evaporator air discharge grille. See paragraph 3-13.
(e) Install fabric cover. See paragraph 3-12.
(7) Lower Front Panel.
(a) Install cover (8) Figure 3-16 and tighten seven captive screws (7).
(b) Install screw (4), new lock washer (5), and flat washer (6).
(c) Install screw (1), new lock washer (2), and flat washer (3).
3-67
