TM 55-1925-284-14&P
0014 00
6. Remove and discard the gasket (figure 8, item 5).
7. Remove the basket (figure 8, item 6) from the wet well inlet strainer (figure 8, item 2).
8. Clean the basket (figure 8, item 6) with fresh water.
ASSEMBLY
1. Install the basket (figure 8, item 6) in the wet well inlet strainer (figure 8, item 2).
2. Install the cover (figure 8, item 4) and new gasket (figure 8, item 5).
3. Swing the yoke (figure 8, item 3) into place and tighten the yoke screw (figure 8, item 1).
4. Remove the lockouts and tagouts (FM-55-502).
5. OPEN valves MSD-8 MEDIA TANK PUMP-OUT DR (figure 4, item 3) and MSD-10 WET WELL DISCHARGE
(figure 4, item 11).
6. Return the MSD to operation under usual conditions (WP 0005 00) and check for leaks.
7. Return the equipment to the desired readiness condition.
END OF WORK PACKAGE
0014 00-12
