TM 9-2320-366-10-2
Table 3-2. Troubleshooting (Cont)
MALFUNCTION
TEST OR INSPECTION
CORRECTIVE ACTION
Check circuit breaker (CB77) on PDP to see if it is tripped.
(a) Position master power switch to off (para 2-27f).
(b) Remove PDP cover (para 3-17a).
(c) If circuit breaker is tripped, push in to reset.
(d) Install PDP cover (para 3-17b).
(e) Position master power switch to on (para 2-27a or b).
(f) If VOLTS gage still does not operate or is inaccurate, notify Unit Maintenance.
(g) Position master power switch to off (para 2-27f).
Check to see if tachometer illuminates.
(a) Position main light switch main selector level to SER DRIVE (para 2-27c).
Change 2
3-36.1/(3-36.2 Blank)
