WIRING HARNESS REPAIR - CONTINUED
ACTION
REMARKS
ITEM
LOCATION
MALE CONNECTOR REPAIR
Slide back.
Shell (2)
Wire lead (1)
1.
Take off.
Washer (3)
2.
Slide off over contact (4).
Shell (2)
3.
Throw away shell (2).
Using cutting pliers, cut off.
Contact (4)
4.
Throw away contact (4).
Strip off insulation equal to the depth
Wire lead (1)
5.
of the new contact (4).
Slide onto wire lead (1).
Shell (2)
Wire lead (1)
6.
Using crimping tool, slide onto wire lead
Contact (4)
7.
(1) and crimp.
Washer (3)
a. Slide onto lead (1).
8.
b. Slide shell (2) over washer (3) and
contact (4).
FEMALE CONNECTOR REPAIR
Slide back on wire lead (5).
Shell (6) and
Wire lead (5)
9.
sleeve (7)
Using cutting pliers, cut off.
Contact (8)
10.
Throw away contact (8).
Wire lead (5)
Strip off insulation equal to the depth
11.
of the new contact (8).
Slide onto wire lead (5).
Shell (6) and
12.
sleeve (7)
a. Using a crimping tool, slide contact
Contact (8), shell
13.
(8) onto wire lead (5) and crimp.
(6), and sleeve (7)
b. Slide shell (6) and sleeve (7) over
contact (8).
