TM 9-2330-213-14&P
This Task Covers:
Intervehicular Vacuum Hose Replacement
a.
c.
Coupling Replacement
Vacuum Line Replacement
b.
Initial Setup:
Equipment Conditions:
Tools/Test Equipment:
General mechanic's tool kit
INTERVEHICULAR VACUUM HOSE REPLACEMENT
a.
NOTE
Right and left side intervehicular vacuum hoses are (11) replaced the same way.
This procedure covers one side.
1.
Remove two screws (12) and clamps (13) from intervehicular vacuum hose (11) and drawbar (14).
2.
Remove intervehicular vacuum hose (11) from coupling (10).
NOTE
Instructions for manufacturing intervehicular vacuum hose (11) are found in
Install new intervehicular vacuum hose (11) on coupling (10).
3.
4.
Install intervehicular vacuum hose (11) to drawbar (14) with two clamps (13) and screws (12).
b. VACUUM LINE REPLACEMENT
NOTE
Right and left side vacuum lines (2) are replaced the same way except right vacuum
line has three clamps (6) and left vacuum line has four clamps.
1.
Remove three screws (5) and clamps (6) from vacuum line (2) and framerail (1).
2.
Remove vacuum line (2) from coupling (10).
Loosen clamp (3) and remove vacuum line (2) from hose (4).
3.
NOTE
Instructions for manufacturing vacuum line (2) are found in Appendix G.
4.
Install new vacuum line (2) on hose (4) and tighten clamp (3).
install vacuum line (2) on coupling (10).
5.
Install vacuum line (2) to framerail (1) with three clamps (6) and screws (5).
6.
