TM 9-2330-213-14&P
4-69. 110-VOLT ELECTRICAL SYSTEM MAINTENANCE (Con't).
20.
Remove four nuts (43), Iockwashers (42), screws (39), insert housing (38), and gasket (41) from elbow
(34). Remove insert (40). Discard Iockwashers and gasket.
NOTE
For repair of wire leads, refer to Paragraph 4-71.
Tag three inlet wire leads (27) and ground wire lead (26) and remove from insert (40).
21.
Remove four nuts (46), Iockwashers (45), screws (44), and elbow (34) from floor (35). Discard
22.
Iockwashers.
TA505346
4-137
