TM 9-2330-357-14&P
5-11. OUTRIGGER ACTUATOR ASSEMBLY REPAIR (Con't). .
7.
Using suitable lifting device, apply light lifting
force to gear housing cover (4). Tap gear
housing cover and lift straight up until all
internal components are clear.
8.
Remove gear housing cover (4) from lifting
device.
9.
Remove seal (7) and gasket (8) from gear
housing cover (4). Discard seal and gasket.
5-28
