TM 9-2330-383-14&P
Section II. OPERATOR TROUBLESHOOTING PROCEDURES
3-3.
SYMPTOM INDEX
Page
ELECTRICAL SYSTEM
All lamps do not light .................................................... 3-9
One or more (but not all) lights will not light .......................... 3-10
Dim or flickering lights ................................................. 3-10
BRAKES
Spring brakes will not release ........................................... 3-11
Grabbing brakes .......................................................... 3-11
Hard pulling ............................................................. 3-12
TIRES
Excessively worn or scuffed tires or flat spots on tires ................. 3-12
3-4.
OPERATOR TROUBLESHOOTING TABLE
a. Table 3-1 lists the common malfunctions which you may find during the
operation of the Heavy Expanded Mobility Ammunition Trailer (HEMAT) or its
the order listed.
b. This manual cannot list all malfunctions that may occur, nor all tests or
inspections and corrective actions. If a malfunction is not listed or it is not
corrected by the listed corrective actions, notify your supervisor.
MALFUNCTION
TEST OR INSPECTION
CORRECTIVE ACTION
ELECTRICAL SYSTEM
1. ALL LAMPS DO NOT LIGHT.
Step 1.
Check lights and fuses on towing vehicle including turn signals and
stop lights.
a.
If towing vehicle lights do not light, notify unit maintenance.
b.
If towing vehicle lights come on, proceed to step 2.
Change 1
