TM 9-2330-386-14&P
4-6 REPAIR INSTRUCTIONS.
NOTE
For accuracy, refer to the Source, Maintenance and
Recoverability (SMR) codes assigned to support items
listed in the maintenance Repair Parts and Special Tools
List (RPSTL) AppendixF in this manual.
a. General.
Any repair procedure peculiar to a specific part or component is
covered in the section or paragraph relating to that item. After repair, clean all
parts thoroughly to prevent dirt, metal chips or other foreign material from
entering any working parts.
b.
Casting,
Forgings,
and
Machined
Metal
Parts.
(1) Minor cracked castings or forgings may possibly be repaired. See your
supervisor and refer to TM 9-237.
WARNING
Dry cleaning solvent (P-D-680) is toxic and flammable.
Avoid prolonged breathing of vapors. Avoid skin contact.
U s e only in a well ventilated area. Keep away from open
flame. Flash point of solvent is 138 F.
(2) Repair minor damage to machined surfaces with a fine mill file or crocus
cloth dipped in dry cleaning solvent (P-D-680).
(3) A deeply nicked machined surface which could affect the assembly operation
should be replaced. See your supervisor.
(4) Minor damage to threaded capscrew holes should be repaired with thread tap
of same size. See your supervisor.
Section II. REPAIR PARTS, SPECIAL TOOLS, TMDE, AND SUPPORT EQUIPMENT
Para
Common Tools and Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Special Tools, TMDE, and Support Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4-7 COMMON TOOLS AND EQUIPHEUT.
For authorized common tools and equipment, refer to the Modified Table of
O r g a n i z a t i o n and Equipment (MTOE) applicable to your unit.
4-5
