TM 9-2590-209-14&P
Section VIII. REWORK OF VEHICLE COMPONENTS FOR KIT INSTALLATION
10-38. General. This section provides instructions for
b. Attach hardware to access door (view B).
preparation and rework of M60, M60A1, M60A1 RISE
and M60A3 tank components prior to installation of the
c. Attach tube and secure with two clamps and
early model M9 bulldozer kit.
hardware (view B).
d. Install clutch adjusting tool 7953545 (view B).
a. Cut out access door (view A).
Section IX. INSTALLATION
f. Connect hose to upper pump connector (view C).
10-40. General.
a. This section contains instructions for installation
NOTE
Prior to installing the mount assembly 7383915, make a
of the early model M9 bulldozer kit.
brake adjustment at the transmission in accordance to
b. The M9 bulldozer kit is shipped with some parts
vehicle requirements.
already assembled, and a number of those assemblies
g. Install mount assembly (view D).
require partial disassembly before installation on the
vehicle. Before disassembling any of the material,
identify each assembled group, loose parts, or individual
NOTE
assembly to make certain no parts are missing.
Install spacer and screw ("A", view E) prior to installing
10-41. Installation of Hydraulic Pump and Power
bracket 7699997.
h. Install bracket onto right side of transmission
(view E).
a. Open engine exhaust access doors.
b.
10-42. Installation of Clutch Control Assembly (Fig.
Remove exhaust elbows and transmission
shroud. See TM 9-2350-215-20 (M60, M60A1), TM 9-
2350-257-20-1 (M60A1 RISE), or TM 9-2350-253-20-1
(M60A3).
NOTE
Rotate lugs on yoke 7699980 to insure freedom of
c. Remove power takeoff access cover.
movement. Remove paint from yoke if binding occurs.
d. Install sprocket assembly in power takeoff (view
a. Install clutch yoke and support bracket (view A).
A).
b. Drill hole, and install housing to left side of vehicle
e. Connect hose loosely to lower pump port, while
(view B).
unit is on the bench (view B).
10-51
