TM 9-4110-256-14
4-44.
GASKET (HEAT SHIELD) REPLACEMENT. - Continued
b. Installation.
(1)
(2)
Install right outside gasket (7), one gasket retainer strip (3), two gasket retainer strips (2), and 13 screws
(1). Repeat for left outside gasket.
(3)
Install right inside gasket (6), three gasket retainer strips (2), and 12 screws (1). Repeat for left inside
gasket.
(4)
Install top inside gasket (5), two gasket retainer strips (2), and eight screws (1). Repeat for bottom inside
gasket.
(5)
Install top outside gasket (4), one each gasket retainer strips (2) and (3), and nine screws (1). Repeat for
bottom outside gasket.
(6)
Coat the cut surfaces of gasket (4), (5), (6), and (7) with silicone RTV to seal foam.
(7)
Seal four seams (8) with silicone RTV.
NOTE
FOLLOW-ON MAINTENANCE:
Install refrigeration unit onto refrigerator enclosure (para 4-6).
Connect power and put unit back into service.
4-94
