TM 9-4110-256-14
5-21.
PRESSURE REGULATOR VALVE (DISCHARGE) REPLACEMENT.
This task covers:
a. Removal
b. Installation
INITIAL SETUP
Materials/Parts:
Equipment Conditions:
Self Locking Nut
a.
Removal.
(1)
De-braze two fittings (1) from pressure regulator valve (2) (para 5-10).
(2)
Remove self locking nut (3), bolt (4), pressure regulator valve (2), and clamp (5). Discard self locking nut.
Figure 5-17. Pressure Regulator Valve
5-43
