TM 94120-371-14
c. Inspection
(1) Check for punctures, cuts, and other visible damage.
(2) Check for packed or mashed areas that would block airflow.
(3) Replace if found bad.
d. Installation. Slide mist eliminator straight down into guides.
NOTE
Be sure that TOP marking is up and that air flow arrow points out away from evaporator
coil and unit.
Follow-on procedure: Install top panel. (See para 4-29.)
4-37. ELECTRICAL WIRING REPAIR GENERAL
Preferred repair methods consist of replacing wires, terminals, connectors, etc., rather than splicing wires,
bending ends to form terminals, and other makeshift procedures; although the latter may be appropriate for
emergency field repairs. Determine the proper size and length of wire, or the terminal, or connector to be used
a. Soldering connections. Wire connections must be made mechanically sound before they are soldered;
solder alone does not provide sufficient strength to prevent breakage. Joining surfaces of connections to be
soldered must be clean and bright. If a separate flux is used, it should conform to Specification MILF14256,
rosin base flux, item 16, Appendix E, and should be brushed onto the joint before soldering. If a flux-core
solder is used, it should always be rosin-core electrical solder. If an uncored solder is used, it should be a
leadtin solder, item 2, Appendix E, conforming to Specification QQ-S-571. Wires should always be heated to
the point at which the solder will melt completely and flow into all parts of the joint. Excessive buildup of solder
"gobs" on the joint should be avoided or removed.
b. Insulating joints. The preferred method of insulating electrical joints is by the use of heatshrink tubing.
To apply, cut a piece of heatshrink tubing of suitable diameter to a oneinch length for covering joints at
terminals or connectors, or to a length about 1/2 inch (1.3 cm) longer than the joint to be insulated, and slide
the tubing over the wire before making the joint. After the joint is made, slide the tubing so that it covers the
joint, and shrink in place with moderate heat.
c. Splicing wires. To repair broken or cut wires that are otherwise sound, the mating ends can be stripped
and spliced. A commercial butt splice can be crimped onto the end to join them, or a "Western Union" wire
splice can be made. The latter is made by stripping 1/4 1/2 inch (0.6 1.3 cm) of insulation from the wire
ends, holding the ends parallel and facing opposite directions, then twisting each end around the other wire at
least three turns. Solder and apply insulation as described above.
d. Crimping terminals. To install a terminal on the end of a wire, strip 1/4 1/2 inch (0.6 1.3 cm) of
insulation from the end of the wire, apply a oneinch piece of heatshrink tubing (if the terminals are of the
uninsulated type), and insert wire end into the shank of the terminal. Crimp the shank, and install heatshrink
tubing, if necessary.
