TM 9-4120-388-14
This task consists of:
a. Removal
b. Test/Replace/Repair
c. Installation
INITIAL SET-UP:
Equipment Condition:
Turn off power.
Disconnect input power to air conditioner before performing any Internal mainte-
nance. Voltages used can KILL. Shutting unit off at control panel does not discon-
nect unit power.
Removal.
a.
(1) Loosen two captive panel fastener screws in lower front panel.
(2) Tip top of lower front panel away from unit and lift panel up to clear flange on bottom of panel.
(3) Loosen six captive turnlock stud fasteners in intake grille assembly.
