TM 9-2330-205-14&P
HANDBRAKE CABLE ASSEMBLY- CONTINUED
ACTION
LOCATION
ITEM
REMARKS
INSTALLATION
6. Backing plate (15)
Handbrake cable (1)
Push end through backing plate (15).
7. Brake
Handbrake cable (1)
Pull back brake lever (14) and hook
lever (14)
cable (1) in lever (14).
8. Backing plate (15)
Two nuts (16),
Using 7/16-inch wrench, secure.
clamp (17), and
handbrake cable (1)
TA223326
