TM 9-2330-213-14&P
4-22. SERVICE AND BLACKOUT TAILLIGHT MAINTENANCE.
This Task Covers:
a.
Lamp Replacement
Installation
c.
b.
Removal
Initial Setup:
Equipment Conditions:
Materials/Parts:
Intervehicular cable disconnected from towing
vehicle (para 2-1 2).
Two lockwashers
Tools/Test Equipment:
General mechanic's tool kit
a.
LAMP REPLACEMENT
NOTE
Service taillight lamps and blackout taillight lamps are replaced the same way except
blackout taillight has two lamps and service taillight has three lamps. -
1.
Loosen six screws (2) and remove door (1) from body (4).
2.
inspect preformed packing (8) for damage. if damaged, remove and discard.
3.
Remove two lamps (6) and lamp (7) from sockets (3) and socket (5) by pushing lamps in and turning
counterclockwise.
4.
Install two new lamps (6) and lamp (7) in sockets (3) and socket (5) by pushing lamps in and turning
clockwise.
-
TA505253
