REMOVAL
NOTE
If towing vehicle is not available, place secure
blocking under front of semitrailer frame. Raise legs
until semitrailer front rests on blocking and pressure
is off of leg to be removed.
It is not necessary to support front of semitrailer to
If replacing right leg only, go to step 7.
If replacing gearbox only, go to step 9.
Nut (3), washer (4),
Left rod coupling
Using 9/16-inch socket, handle, and 9/16-
1.
and screw (5)
(1) and rod (2)
inch wrench, unscrew and take out.
NOTE
Be sure leg is securely supported before unbolting
from frame.
Eight nuts (8), 16
Left leg (6) and
Using 15/16-inch socket, handle, and
2.
washers (9), and
frame (7)
15/16-inch wrench, unscrew and take out.
eight screws (10)
Two nuts (12)
Leg-to-frame
Using 7/8-inch wrench, unscrew and take
3.
U-bolt (11)
off.
