TM 9-4110-258-13
a. Installation.
NOTE
Mounting hardware is not supplied with the unit.
See enclosure manual for information on
appropriate hardware to use.
(1) Attach the sling(s) to the reinforced lifting holes.
CAUTION
Failure to use a spreader bar or two point lifting device, such as a fork lift, can cause damage to
(2) If a single point lifting device is being used, install the spreader bar onto the sling(s) at approximate mid-
way point.
WARNING
The refrigeration unit can swing and move when lifted. Personal injury can result if standing near
unit when it is lifted.
(3) Connect a hoist or similar lifting device to the sling(s) and lift the refrigeration unit.
Figure 4-2. Installation
4-3
