TM 9-4935-481-14-1
C2
Table 3-2. Monitor SELECTOR Switch Functions-Continued
Table 3-2. Monitor SELECTOR Switch Functions
SELECTORS A,B,C
MONITORS
DESCRIPTION/REMARKS
SELECTORS A,B,C
MONITORS
DESCRIPTIVE/REMARKS
A-1
J7-1
+ Battery (filtered)
B-10
J7-22
Dynamic Hold Gate (XA6-62)
2
J7-2
-Battery (filtered)
11
J7-23
3
J7-3
+13 Vdc (direct)
12
J7-24
4
J7-4
13
J7-61
Freq. Select Tens Bit-4
5
J7-5
-13V Crowbar Test (XA24-57)
14
J7-62
Freq. Select Tens Bit-8
6
J7-6
+13V Crowbar Test (XA24-55)
15
J7-63
Trainer Freq. Stimulus
7
J7-7
+5V Crowbar Test (XA24-51)
16
J7-64
Squelch Low Inhibit T.P.
8
J7-8
17
J7-65
Trainer Trigger Gate
9
J7-9
18
J7-66
Trainer Trigger Switch
10
J7-10
19
J7-67
Squelch High Stimulus T.P.
11
J7-11
20
J7-68
IR Mon Signal Rectified T.P.
12
J7-12
Test Power Gate
21
J7-69
Timer Current Input
13
J7-49
Vert. Squelch Gate (XA12-86)
22
J7-70
+15 Vdc Charger Voltage
14
J7-50
23
J7-71
-15 Vdc Charger Voltage
15
J7-51
Vert. Clamp
24
J7-72
Batt. Mon. Thermistor Low
16
J7-52
Squelch False Sample
17
J7-53
C-1
J7-25
18
J7-54
2
J7-26
19
J7-55
Freq. Select Units Bit-1
3
J7-27
20
J7-56
4
J7-28
21
J7-57
5
J7-29
22
J7-58
6
J7-30
23
J7-59
7
J7-31
24
J7-60
8
J7-32
B-1
J7-13
Trigger Output Inhibit
9
J7-33
2
J7-14
Boresight Inhibit (XA5-38)
10
J7-34
3
J7-15
11
J7-35
4
J7-16
12
J3-36
5
J7-17
13
J7-73
Pulse Width Comparator Output T.P.
6
J7-18
14
J7-74
Horiz. Error DC Voltage T.P.
7
J7-19
15
J7-75
Batt/Timer Current Analog T.P.
8
J7-20
16
J7-76
Transformer Sec. High
9
J7-21
17
J7-78
Charging Indicator
