TM 9-2330-285-14&P/TO 36A11-21-10-1
REAR SPINDLES
This task covers:
INITIAL SETUP
Tools - Continued
Tools
3/4-inch wrench
9/16-inch wrench
Socket, 9/16-inch by 3/8-inch
Equipment Condition
drive
Handle, reversible ratchet, 1/2-inch
Hub and brake drum removed
Square drive
5/8-inch wrench
3/8-inch wrench
ACTION
ITEM
REMARKS
LOCATION
REMOVAL
Remove using 3/8-inch and 5/8-inch wrenches.
1 Wheel cylinder (1)
Brake hose (2)
Remove using a 9/16-inch wrench and a 9/16-
Six screws (5)
2 Spindle (3) to
inch socket wrench.
backing plate (4)
and six nuts (6)
a. Remove two screws (9), two washers (11)
Two screws (8),
3 Spindle (3) to
and two nuts (10) using two 3/4-inch
two screws (9),
axle beam (7)
wrenches.
two nuts (10) and
b. Remove two screws (8) and two washers (11)
four washers (11)
using a 3/4-inch wrench.
c. Remove spindle (3) from between backing
plate (4) and axle beam (7).
Backing plate (4) will remain
attached to the handbrake cable.
INSTALLATION
Position into backing plate (4) and on axle
Spindle (3)
4 Backing plate (4)
beam (7).
and axle beam (7)
a. Install two screws (8) and two washers
Two screws (8),
5 Spindle (3) to
(11) using a 3/4-inch wrench.
two screws (9),
axle beam (7)
b. Install two screws (9), two nuts (10) and
two nuts (10) and
two washers (11) using two 3/4-inch
four washers (11)
wrenches.
