TM9-2330-374-14&P
Installation.
b.
Secure with four screws (18).
wiring through holes in top.
(2) Position switch box (12) on wall and insert wiring. Secure with four
screws (19).
(3) Slide rigid coupling (20) over wiring.
(4) Thread wiring through bottom of load center (4).
Slide locknut (17) over
w i r i n g . Tighten locknut (17).
(5) Install and tighten two locknuts (15 and 16) in switch box (12).
(6) Install close nipples (13 and 14) at top of load center (4).
(7) Install caps (10 and 11) in switch box (12).
(8) Install caps (7, 8 and 9) in circuit breaker load center (4).
(9) Remove tags and connect all internal wiring in switch box (12) and circuit
breaker load center (4).
(10) Install wire run covers (6) at top of load center (4).
( 1 1 ) Close door (2) on switch box (12).
center (4).
4-16. 110 VOLT WALL RECEPTACLE REPLACEMENT
INITIAL SETUP
Tools
General mechanics tool kit
Materials/Parts
110 volt receptacle
WARNING
D i s c o n n e c t all outside power before performing any
Failure to do so
maintenance on the electrical system.
could result in serious injury or death.
Removal.
a.
(1) Turn locking screw (1, figure 4-2) one quarter turn to unlock receptacle
(2) in wire run (3).
