TM 9-2350-222-10-3
MAINTAIN TRACK (BREAK TRACK)
NOTE
Two crewmembers are needed to do this
procedure.
Tools:
Get crowbar (A) from left front fender box.
Make Sure:
q Vehicle is stopped on hard level surface.
q Engine is not running.
1.
Loosen track tension (page 3-62).
2.
Remove inner (B) and outer (C) end
connectors (page 3-64).
3. Remove centerguide (D) (page 3-69).
TA132901
