TM 9-2350-222-10-2
OPERATE WINCH (PREPARE FOR WINCHING OPERATIONS)
NOTE
Operating
the
winch
requires
three
crewmembers: Commander, Driver, and outside
Crewmember.
Make Sure:
Turret is traversed (page 2-502) so boom is over driver's
compartment.
1. Position vehicle (A) as squarely as possible to load (B).
2. Start hydraulic system (page 2-249).
3. Prepare moldboard for operations (page 2-253).
4.
Lower moldboard to ground (page 2-257) to stabilize vehicle
during winching operations.
5. Set SELECTOR VALVE lever (C) to TURRET.
6. Depress accelerator pedal (D) until tachometer (E) shows 1100
rpm.
7. Pull up and hold accelerator locking lever (F) to maintain engine
speed at 1100 rpm.
TA252748
8. Release accelerator pedal (D).
9. Release accelerator locking lever (F).
Change 1
2-269
