WALL RECEPTACLES AND BASE, 11O-VOLT
This task covers:
a. Removal (page 4-32)
b. Installation (page 4-33)
INITIAL SETUP
Tools - Continued
Tools
Screwdriver, cross-tip, number two
Drill, electric, portable, 1/2-inch
Screwdriver, flat-tip, 3/16-inch
Drill, twist, 3/16-inch
Hacksaw, hand
Personnel Required
Hammer, hand, ball-peen
Pliers, diagonal cutting
One
ACTION
ITEM
REMARKS
LOCATION
WARNING
Contact with live 110-volt electrical wires could result in serious injury or death. Make
sure power source is disconnected before performing maintenance on the electrical
system.
NOTE
All wall receptacles and bases are removed and installed the same way. This task is for
one section; repeat for the others.
REMOVAL
Two covers (2)
Using 3/16-inch flat-tip screwdriver,
1.
Base (1)
pry off.
NOTE
Tag wires to aid in installation (page 4-4). If circuit marker bands are missing or not
readable, replace (page 4-73).
Screw (4)
Using 3/16-inch flat-tip screwdriver,
2.
Wall
unscrew one-quarter turn.
receptacle (3)
Wall receptacle (3)
Take off.
3.
and two wires (5)
Two contact
a. Using 3/16-inch flat-tip screwdriver
4.
Wall
screws (6) and
unscrew screws (6) part way
receptacle (3)
two wires (5)
b. Pull wires (5) off screws (6).
4-32
