TM 9-2330-227-14&P
LAMP BOX - CONTINUED
ACTION
REMARKS
ITEM
LOCATION
INSTALLATION - CONTINUED
Screw in, and tighten using 7/16-inch soc-
Three Iockwashers
9. Box (1) and
ket extension, ratchet handle with 3/8-
(6), screws (5),
frame member (4)
inch drive, and 7/16-inch box-end wrench.
and nuts (7)
a. Close lid (3).
Hook clamp (2)
10. Box (1)
b. Lift and hook clamp (2).
and lid (3)
INSIDE PANELING AND INSULATION
This task covers:
a. Removal (page 4-174)
b. Installation (page 4-174)
INITIAL SETUP
Equipment Condition - Continued
Tools
Inside domelight, 24-volt, removed
Screwdriver, cross-tip, number two
Inside domelight, 110-volt, removed
Personnel Required
Junction boxes removed (page 4-42)
Two
(where necessary).
Light switches removed
Equipment Condition
Screens removed (page 4-163)
Data plates removed (page 4-186)
(where necessary).
(where necessary).
Wall receptacles and base removed
Door switches removed (page 4-37)
TA231319
(where necessary).
4-173
